| CPU | Atheros AR9132+AR9103 |
| Installed Buffer Memory Storage Capacity | 32 MB |
| Installed Flash Memory Storage Capacity | 8 MB |
| Data Link Protocol Supports | Gigabit Ethernet/Fast Ethernet/Ethernet IEEE 802.11b/g/n |
| Local Area Network Architecture | 10Base-T/100Base-TX/1000Base-TX Wireless |
| Data Bit Rate | 300 Mbps |
| Network/Transport Protocol | PPPoE TCP/IP UDP DHCP SNTP QoS |
| Data Transmission | Full Duplex |
| Frequency | 2.4 GHz |
| Line Modulation Type | CCK DBPSK DQPSK OFDM QPSK |
| Max. Range Indoors | 100 m |
| Max. Range Open Space | 300 m |
| Encryption Algorithm | 128-bit WEP 152-bit WEP 64-bit WEP |
| Networking Compliant Standards | IEEE 802.11b IEEE 802.11e IEEE 802.11g IEEE 802.11i IEEE 802.3 IEEE 802.3ab IEEE 802.3u IEEE 802.11n |
| Networking Features | DHCP Server Built-in WPA (Wi Fi Protected Access) Support Web Interface WPA2 MAC address filtering |
| Antenna | External |
| Device Location | External |
| Mounting Capability | Desktop |
| Ethernet 10Base-T/100Base-TX/1000Base-T Port Quantity | 4 |
| Ethernet 10Base-T/100Base-TX/1000Base-T Port Connector Type | RJ-45 |
| Antenna Connector Quantity | 3 |
| Antenna Connector Type | SMA |
| USB2.0 Interface Quantity | 1 |
| WAN Ethernet 10Base-T/100Base-T/1000Base-T Port Quantity | 1 |
| WAN Ethernet 10Base-T/100Base-T/1000Base-T Port Connector Type | RJ-45 |
| Power Device Location | External |
| Depth | 190 mm |
| Height | 144 mm |
| Width | 32 mm |
| Nominal Weight | 0.4 kg |
| External Color | Black/White |
| Warranty Products returnable | Yes |
| Warranty Term (month) | 24 month |
| Warranty validation Criteria | Serial Number |
| Pack Depth (mm) | 285 mm |
| Pack Width (mm) | 223 mm |
| Pack Height (mm) | 68 mm |
| Pack Weight Brutto (kg) | 0.6 kg |
| Pack Weight Netto (kg) | 0.5 kg |
| Pieces in pack | 1 |
| Box Depth (mm) | 585 mm |
| Box Width (mm) | 460 mm |
| Box Height (mm) | 285 mm |
| Box Weight Brutto (kg) | 10.6 kg |
| Packs in Box | 16 |
| EAN Code | 8717371853488 |
